SCANGRIP DETAILING LIGHTING QUICK GUIDE

Good lighting in detailing isn't just about making the workshop brighter.

The right light helps you see what you're actually working on, dirt in interiors, missed areas, polish residue, coating high spots and imperfections that normal workshop lighting can hide.

NOVA 6 C+R → LARGE AREA / DETAILING BAY

NOVA 4 C+R → GENERAL DETAILING / WORK AREA

NOVA R → PORTABLE / WORK AROUND THE CAR

FLASH PEN R → CLOSE INSPECTION / TIGHT AREAS

DIFFUSER → SOFTER, SPREAD-OUT LIGHT

SCANGRIP NOVA 6 C+R – LARGE DETAILING BAY / MAXIMUM AREA LIGHT

The NOVA 6 C+R is the most powerful light of these options, producing up to 6000 lumens with a wide 110° beam angle.

It's designed to throw a large amount of even light across a working area, making it excellent for professional detailing studios, wash bays, garages, engine bays and larger work areas.

A major advantage is the C+R Dual System, meaning it can operate cordless from its rechargeable battery or connected to its 5-metre power cable.

It has 6 adjustable output levels from 600–6000 lumens, so you don't have to use maximum brightness all the time.

At maximum output, battery runtime is approximately 1.5 hours, increasing up to around 15 hours at minimum output.

Best for: Professional detailing studios, larger garages, workshops and customers wanting maximum area lighting.

Good choice for:

  • Lighting an entire side of a vehicle

  • Large detailing bays

  • Interior detailing

  • Engine bay work

  • Under-car work

  • General workshop lighting

  • Tripod-mounted lighting

  • Professional everyday use


"If you want to light up a large section of the car or an entire detailing work area, the NOVA 6 is the one. You've got up to 6000 lumens and you can run it cordless or plug it in for longer jobs."

SCANGRIP NOVA 4 C+R – GENERAL DETAILING / GREAT ALL-ROUNDER

The NOVA 4 C+R is the smaller brother to the NOVA 6 and is probably the easier choice for someone who doesn't need 6000 lumens.

It produces up to 4000 lumens with the same wide 110° beam angle and also uses the C+R Dual System, so it can operate from its battery or the supplied 5-metre power cable.

It has 6 adjustable light levels from 400–4000 lumens.

Battery runtime is approximately 2 hours at maximum output and can reach around 18 hours at minimum output.

It's a great option for home garages, professional detailers and mobile detailers wanting plenty of usable area light without stepping up to the larger NOVA 6.

Best for: Home detailing garages, mobile detailers, professional detailers and general workshop use.

Good choice for:

  • General detailing

  • Interior cleaning

  • Engine bays

  • Wheel and wheel-arch work

  • Working around individual panels

  • Garage lighting

  • Mobile detailing

  • Tripod-mounted lighting


"If you want a proper detailing work light but don't need the output of the NOVA 6, the NOVA 4 is a great all-rounder. You've still got 4000 lumens and both cordless and plugged-in operation."

NOVA 6 C+R VS NOVA 4 C+R

This is an easy customer question:

"Do I need the 4 or the 6?"

The main difference is how much area and brightness they need.

NOVA 4 C+R → Up to 4000 lumens

NOVA 6 C+R → Up to 6000 lumens

For a normal home garage or general detailing:

→ NOVA 4 C+R is usually plenty.

For a larger professional studio or someone wanting more light across a larger working area:

→ NOVA 6 C+R makes more sense.

Don't automatically sell the 6 because it has the bigger number.

Sometimes too much concentrated light can actually make inspection harder because of glare and reflections.

That's where adjusting the brightness, or adding a DIFFUSER... becomes important.

SCANGRIP NOVA R – PORTABLE ALL-ROUNDER

The NOVA R is where things become much more portable.

It produces up to 2000 lumens, but instead of primarily being a large stationary work light, it's designed to be compact, rechargeable and easy to move around the vehicle.

It has a flexible handle with strong integrated magnets, so you can position it on suitable metal surfaces and angle the light towards the area you're working on.

It also has 6 adjustable output levels from 200–2000 lumens and a wide 110° beam.

This makes it extremely useful for detailers because you're not always trying to illuminate the entire workshop, sometimes you just need good light exactly where you're working.

Best for: Mobile detailers, interior detailers, home users and professionals wanting a portable light.

Good choice for:

  • Vehicle interiors

  • Footwells

  • Under seats

  • Engine bays

  • Wheel arches

  • Working around individual panels

  • Mobile detailing

  • Spotting areas you've missed while cleaning

  • Moving around the vehicle during a detail


"If you don't need to light the whole workshop and want something you can grab and move around the car, the NOVA R is the better option. It's compact, magnetic, rechargeable and still gives you up to 2000 lumens."

SCANGRIP FLASH PEN R – CLOSE INSPECTION / TIGHT AREAS

The FLASH PEN R does a completely different job.

It's a small rechargeable pen-style inspection torch producing 150 lumens normally or up to 300 lumens in Boost mode.

The important feature isn't simply the lumen number — it's the adjustable focus.

You can change the beam angle from approximately 10° to 60°, allowing you to go from a concentrated inspection beam to a wider light.

For detailing, this is perfect when you want to get your eyes right onto a particular area rather than lighting an entire panel.

Best for: Every detailer. Great secondary inspection light.

Good choice for:

  • Looking under seats

  • Seat rails

  • Air vents

  • Door jambs

  • Engine bays

  • Checking wheels

  • Checking cracks and crevices

  • Finding dirt in dark areas

  • Close inspection

  • Keeping in your pocket while working


"The FLASH PEN isn't designed to light the whole car. It's the little inspection light you keep in your pocket for looking under seats, into vents, around engine bays and anywhere your big light can't easily reach."

SCANGRIP DIFFUSER – SOFTEN & SPREAD THE LIGHT

The SCANGRIP Diffuser isn't another light, it's an accessory that changes how the light behaves.

It attaches to compatible SCANGRIP lights and softens and spreads the light, reducing harsh reflections, glare and hard shadows.

This is particularly useful in detailing because automotive paint can be extremely reflective.

Instead of having one harsh bright reflection staring back at you, the diffuser creates a softer and more even working light.

SCANGRIP specifically recommends diffused light for tasks such as checking coating high spots, as well as paint/body work.

Best for: Ceramic coating, interior work and situations where harsh reflections are making it difficult to see.

Good choice for:

  • Checking ceramic coating high spots

  • Coating application

  • Interior detailing

  • Creating softer workshop lighting

  • Reducing glare

  • Reducing harsh shadows

  • Paint and body inspection

  • General working light


"The diffuser doesn't make your light more powerful, it makes it softer and more even. It's really useful when a bright direct light is reflecting back at you or when you're checking coatings."

HOW TO CHOOSE THE RIGHT LIGHT FOR THE JOB

The easiest thing for staff to ask is:

"What are you actually trying to see?"

"I NEED TO LIGHT UP MY WHOLE DETAILING AREA."

→ NOVA 6 C+R

Especially suited to professional studios and larger work areas.

"I WANT A GOOD GENERAL-PURPOSE DETAILING LIGHT."

→ NOVA 4 C+R

Great balance of size, output and versatility for home or professional detailing.

"I WANT SOMETHING PORTABLE I CAN MOVE AROUND THE CAR."

→ NOVA R

Compact, rechargeable, magnetic and easy to position where you're actually working.

"I NEED TO LOOK UNDER SEATS AND INTO SMALL AREAS."

→ FLASH PEN R

Small, focused inspection light that can stay in your pocket.

"I'M APPLYING A COATING AND THE LIGHT IS TOO HARSH."

→ ADD A DIFFUSER

Softens and spreads the light and makes it easier to see across reflective surfaces.

A GOOD PROFESSIONAL DETAILING SETUP

Rather than having one extremely bright light, a professional detailer will generally benefit more from having different lights for different jobs.

A very useful setup would be:

NOVA 6 C+R → Main detailing bay light

NOVA R → Portable light around the vehicle

FLASH PEN R → Close inspection

DIFFUSER → Coating / softer working light

For a home enthusiast or someone starting out:

NOVA 4 C+R → Main work light

Then add:

FLASH PEN R → Close inspection

IMPORTANT STAFF TIP – MORE LUMENS DOESN'T ALWAYS MEAN BETTER

Don't sell detailing lights purely on the biggest lumen number.

A 6000-lumen NOVA 6 is fantastic for illuminating a large work area, but that doesn't mean it's the best tool for looking underneath a seat.

Likewise, a 300-lumen FLASH PEN R sounds much less powerful, but its concentrated adjustable beam makes it far more useful when inspecting a small, dark area.

Think about it like detailing equipment:

NOVA 6 C+R = LIGHT THE AREA

NOVA 4 C+R = GENERAL WORK LIGHT

NOVA R = BRING THE LIGHT TO THE JOB

FLASH PEN R = INSPECT THE DETAIL

DIFFUSER = SOFTEN THE LIGHT

ONE LINE FOR STAFF TO REMEMBER

Don't ask "How bright do you want it?"

Ask:

"What are you trying to see?"

Then choose the light that puts the right type of illumination on that job.
